Ebike C961 LCD Display UART protocol forBafang BBS01 BBS02 BBSHD

Ebike C961 LCD Display UART protocol forBafang BBS01 BBS02 BBSHD Mid-drive motor

• Display Only Applicable To Bafang Mid/Hub Drive Motor Kits

• Communication Protocol:BF-UART

• Connector: 5PIN Female Circular Connector

Note：If your motor is not Bafang brand,these goods not fit for you,if your motor kits use other Communication Protocol,this display not fit for you too,please contact with us before you make order except you make sure our display fit for you .We can also customize the display.

Other Related Information

UART has two protocols, BF-UART and 5S-UART, which are not universal. General UART protocols can be determined by the connector，most of the 5pin circular connector uses the BF-UART protocol, while the male connector uses the 5S-UART protocol.The CAN protocol uses triangular connectors.

Highlights:

• C961 LCD E-Bike Display

• Compatible with Bafang Motor Kits

• See Battery level, speed, distance, power and etc

• LCD Display Panel

Product description:

The C961 offers many functions for your riding pleasure. These Include: Multiple Power levels settings (Mode) Remaining Battery Capacity Speed (Speed/ MAX/AVG)Distance and Odometer (TRIP/ TOTAL) Time Assist walking (slow speed motor assist) Backlight Error codes.

Caution: Do not plug in or unplug this display when the power to the unit is on. Avoid collisions. Protect the display’s membrane to provide water resistant performance. Do not attempt to reset parameters if the display is not working. Call for service if the C961 display is not working. Installation: Install the display and button control on the handlebar and adjust its location. Plug it into the controller with power off.
